Challenger VLE10
Challenger VLE10
Challenger VLE10
Challenger VLE10

Challenger VLE10

$5,788.00

The Challenger VLE10 is a shop equipment unit. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.

In Stock
Category:
Brand:

Description

  • 3-Stage Versymmetric® front arms and 2-Stage rear arms provide a wide arm sweep for asymmetric and symmetric lifting in the same service bay.
  • 11.875” standard height fits in service bays with 12’ ceiling height.
  • Double telescoping screw pads with rubber foot pad.
  • Padded overhead shut-off system prevents vehicle damage.
  • Jacketed pulley-less single-point mechanical lock release system that was once exclusive to our CL series lifts are now standard on the VLE10.
  • Rubber door guards protect vehicle from door damage.
  • Premium powder coat finish provides long-lasting durability.
  • Plated arm restraints and arm pins inhibit rust and provide long-lasting durability.

Specs

SKU# 6010127
Lifting Capacity 10,000 lbs.
Lifting Configuration Symmetric and Asymmetric
Arms 3-Stage Versymmetric® Front/2-Stage Rear
Max Load Per Arm 2,500 lbs
Rise Height (screw pads at highest position) 74.75″
Overall Height Standard: 143.875″ Extended Height: 167.875″
Overall Width 131.625″
Drive-Thru Clearance 98.375″
Floor to Overhead Switch Standard: 137″ Extended Height: 161″
Front Arm Reach 22.3125″-39.375″
Rear Arm Reach 38.375″-55.375″
Screw Pad Height 4.25″-6.75″
Between Columns 110.25″
Motor / Voltage 2HP, 208v-230v, 60Hz, 1Ph
Rise Time 44s
Ceiling Height Required Standard: 12′ Extended Height 14′

Call 216-250-6666 or email sales@varietyengines.com with your ceiling height, floor and power supply and we will check the install and freight with you before you order. More SHOP EQUIPMENT.
