Challenger EV1220 12000 lb ALI Certified Heavy Duty Inground Car Lift

$13,324.00

The Challenger EV1220 is a 12,000-lb. ALI Certified inground lift. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.

In Stock
Category:
Brand:

Description

Challenger EV1220 12000 lb ALI Certified Heavy Duty Inground Car Lift

  • 12,000 lb. lift capacity
  • 3-stage front and 3-stage rear arms provide access to the lift points of a wide range of cars and trucks within the service bay, maximizing revenue potential
  • 8 1/2” diameter chrome pistons provide greater stability under load
  • Chrome non-breathing ram style cylinder provides for longer lift life
  • Enhanced raised wiper at top and bottom of bearing provides better grease retention and minimizes contaminates from entering into bearings
  • Long bearing contact provides increased stability
  • Mechanical lock engages every 3? allows ergonomic working height for technicians to increase productivity and minimize fatigue
  • Stainless steel air lock release cylinder promotes longer working life with its corrosion resistant design
  • Fully-contained and sealed recycled polymer cassette tub eliminates risk of hydraulic fluid seeping into the ground
  • Heavy-duty polyurethane screw pads accommodate a wide range of recommended lifting points
  • 87″ drive-thru accommodates wider vehicles, minimizes tire damage and provides for easy drive-on
  • Wide range of upgrades to further customize your fleet
  • Premium powder coat finish on bolsters and arms provides long-lasting durability
Model Number EV1220
Lifting Capacity 12,000 lbs.
Arms 3-stage front/3-stage rear
Stroke 68”
Rise Height 80.75”
Width Overall 115”
Drive-Thru Clearance 87”
Reach (Arm Minimum) 19.625”
Reach (Arm Maximum) 48”
Screw Pad Height 5” – 6.75”
Capacity 3,000 lbs. per arm
Guide Plunger Diam. 8.5”
Motor / Voltage 2HP, 208v-230v, 60Hz, 1Ph
Speed of Rise 60 s
Air Required 90 – 120 psi
ALI/ETL Certified Yes
Super Structure Colors Red, Blue, Black
