Rotary
VE-8473
Rotary ARO22 22,000 lb ALI Certified Four-Post Heavy-Duty Open-Front Alignment Lift + Rolling Jacks
In stock
Cleveland, OH · Freight across the United States

In stock — ships in 1–2 business days
Call with your VIN or tag number and we will confirm this listing fits before you pay.
The open-front design allows technicians to move easily under the vehicle with no cross bar to get in the way. Carts, oil pans and other essential tools can move in and out freely with no obstructions.
All Rotary four-post lifts feature our patented Dual-Function Sentinel Lock system, which features a slack cable guide arm that rides with the cable and stays “on guard” to manage the lock latch should there ever be an unforeseen cable issue.
Our four-post alignment systems are alignment-ready and compatible with all “new technology” alignment systems today—including Rotary's versatile towerless, portable handheld alignment systems.
| Specification – ARO14 | ARO14-L | ARO14-EL |
| Max. Wheelbase | 182″ | 215″ |
| Max. Two Wheel Align | 171 1/4″ | 209″ |
| Max Four Wheel Align | 164 3/4″ | 164 3/4″ |
| Min. Four Wheel Align | 89″ | 89″ |
| Rise | 78 3/4″ | 78 3/4″ |
| Length Overall | 21′ 1″ | 23′ 10″ |
| Width Overall | 11′ 8 1/2″ | 11′ 8 1/2″ |
| Inside of Columns | 116 1/4″ | 116 1/4″ |
| Between Front and Rear Columns | 194 3/4″ | 227 3/4″ |
| Height of Columns | 9′ 1 1/16″ | 9′ 1 1/16″ |
| Width of Runways | 20″ | 20″ |
| Height of Runways | 7″ | 7″ |
| Width Between Runways | 43″ | 43″ |
| Front of Runway to Center of Radius Gauge | Adj. 18″-24″ | Adj. 18″-24″ |
| Lifting Capacity | 14,000 lbs. | 14,000 lbs. |
| Motor | 2 HP | 2 HP |
| Voltage Single Phase | 208v-230v | 208v-230v |
| Time of Full Rise | 65 seconds | 65 seconds |
| Min. Bay Size | 15’x26′ | 15’x28′ |
Call 216-250-6666 or email sales@varietyengines.com with your ceiling height, floor and power supply and we will check the install and freight with you before you order. More Alignment Lifts.
