$6,595.00

The BendPak RBJ25000 is a 25,000-lb. rolling bridge jack. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.

In Stock
Category:
Brand:

Description

Rubber contact pads

The point of contact on your vehicle frame is the most important part of lifting. So, we make the  rubber contact pads on our bridge jacks hard and durable enough to lift the monsters in your shop. Heavy-duty fleets are no problem for the RBJ25000.

Stackable adapters

All those firetrucks, dumpster trucks, Greyhound™ Buses, etc. have extended lift points and raised chassis. That’s why we include a stackable adapter set with every bridge jack sold. We also recommend you consider the optional truck adapter set, whose frame cradle design ensures heavy frames down shift off the lift pad.

High-pressure hydraulic power unit

A powerful pneumatic-hydraulic power unit creates a dedicated power source for the rolling bridge jack. Two jacks will have separate airlines that can connect together on an airline kit. The foot pedal is air-powered, so a few simple pushes and the jack is fully lifted.

Three lock levels

Lift to three lock positions for your convenience. The higher the jack, the more undercarriage clearance you get on your four-post lift. Every rolling bridge jack offers premium safety standards at every lock position. The RBJ25000 is over-engineered to easily raise 25,000 lbs. in seconds flat.

Features

  • 25,000-lb. lifting capacity
  • Rubber contact pads
  • Stackable adapters
  • High-pressure hydraulic power unit
  • Optional air-line kit

RBJ25000 Specifications

Capacity

Lifting Capacity* 25,000 lbs. (11,340 kg)

Rise

A – Max. Height + Pad Only: 23″ (584 mm)

B – Max. Height + Pad + Adapter: 26″ (660 mm)

C – Min. Height + Pad Only: 17″ (432 mm)

D – Min. Height + Pad + Adapter: 18″ (457 mm)

Time to Full Rise: 45 seconds

Reach

F – Support Arm Width: 44.9″ (1,140 mm) –

G – Max. Arm Reach: 63.5″ (1,613 mm)

H – Min. Arm Reach: 39.5″ (1,003 mm)

Power Unit

Motor: Air-Hydraulic Pump

Noise: 45 dB

Shipping

Weight: 802

Dimensions: 36″ x 22″ x 21″ / 914 mm x 559 mm x 533 mm

Included commercial-grade air-hydraulic pump requires 125 psi and 10 – 20 CFM.

Call 216-250-6666 or email sales@varietyengines.com with your ceiling height, floor and power supply and we will check the install and freight with you before you order. More Four Post Bridge Jacks.
