Is this BendPak Pipe Bender new?

This is a new unit shipped in original manufacturer packaging.

How much does shipping cost?

$150 flat rate shipping applies to all orders. Items ship freight from our Cleveland, Ohio facility, typically within 1–2 business days after payment confirmation.

What payment methods are accepted?

Variety Engines accepts bank transfer (ACH or wire), Zelle and Chime. Card payments are not available. Payment details are emailed after you place your order — nothing is charged at checkout.

BendPak

BendPak Pipe Bender

SKU VE-10224Condition New

$12,195.00

In stock — ships in 1–2 business days

The BendPak Bender is a shop equipment unit. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.

Call 216-250-6666

Call with your VIN or tag number and we will confirm this listing fits before you pay.

Shipping: Freight, 3–6 business days
Returns: 45 days, by mail
Warranty: See warranty terms
Payment: Bank transfer, Zelle, Chime

Product details

Go Manual and Control Your Bends

The BB-2 offers outstanding performance and simple operation. BendPak took their standard bender and equipped it with a knee valve and degree plate combination for a straightforward, rugged design that won’t let you down. Thanks to the knee operated valve, you’ll have precise control as well as hands-free bending capabilities. All you’ll need to do is push the lever to the left to advance the bending die, and then to the right to retract it. Heavy-duty cast iron construction guarantees that the valve will be able to stand up to years of heavy use.

180° bending capacity

BendPak has designed this bender for the shop that needs a bender with an extremely deep bending capability, and they believe that their U-shaped design is up to the task. Just make sure to ask for their 180° dies if you’re planning to bend more than 170°. This bender will deliver perfect, deep bends on a 5” radius, without pipe sticking or hang-ups. That’s because BendPak utilizes an exclusive relief cut design on their bending dies which help maintain the pipe’s uniformity throughout the bend cycle and eliminate excessive crimping or deformation.

3" bending capacity with die kit

Every BendPak bender includes a convenient 3” bending capacity. Their 3” bending dies are anything but average. They use an exclusive step-cut process for the die rails. BendPak uses better-contained, larger-sized tubing for a more uniform bend. Although this is technically a bender, it’s still capable of expanding and flaring too! You’re also able to choose from a full range of exclusive dies.

Long-stroke bending cylinder

Since every BendPak bender is equipped with an extended-top cylinder, you won’t need to use pusher block extensions when bending with small-radius dies. Also, the 14” top-cylinder can be retracted further, providing additional clearance for changing dies or removing bent tubing.

Features

2 separate end-finishing units at rear for all necessary flaring and expanding Knee control and depth-of-bend degree plate for manual bending operations BB-2 Tooling Package included Comes complete with quick release bending and finishing dies Includes high-speed clampless swager and internal expander Easy-to-use drop-in collar makes swaging operations quick and efficient Twist-lock tooling Integrated power-relief control valve Pass-through cylinder stem passes completely through the primary frame Rigid 6" x 6" x 3/8" welded-steel tube frame Commercial-grade hydraulic cylinders All cylinders feature chrome-molly shafts, conforming to ANSI 92.2 standards Quick-release bending dies for reduced set-up times Bending heads precision grounded to within .002" Enclosed controls keep your bending area clutter-free 2.5" oversized barrel shafts for maximum dependability and minimum maintenance Standard grease fittings allow for simple lubrication NEMA-rated on / off switch box incorporates overload relays that automatically disrupt power supply should an unforeseen over-current situation occur Pressure gauges let you know exactly what the system pressures are at all times Industrial grade casters help you easily move the bender around your shop Adjustable pressure valve located right up front One-piece barrel ensures that the bending gates stay perfectly aligned with the ram Heat-treated tooling for greater service life Convenient tool trays keep your tooling organized Strong, 5 HP Baldor energy efficient motor delivers maximum performance Direct-drive, high-speed, 4 gpm pump Single enclosed bottom cylinder applies pressure evenly to the back gates and, because it is hidden, does not interfere with the tubing Large capacity fluid reservoir keeps the hydraulic oil running cooler and prevents contamination Canister oil filter in the hydraulic system keeps the oil nice and clean Oil sight-gauges allow you to visually inspect oil levels Over-sized 1/2" high-pressure hose provides better speed and cooling Open-sided swager box allows for easier access and reduces the chance of "crashing" tools and damaging the cylinder 180° bending die available
