Mahle
Mahle CAD-EL 9,000 lb. End Lift Adapter
SKU VE-9098Condition New
$3,669.00
In stock — ships in 1–2 business days
The Mahle CAD-EL End Lift Adapter is a 9,000-lb. mobile column lift. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.
Call with your VIN or tag number and we will confirm this listing fits before you pay.
- Shipping
- Freight, 3–6 business days
- Returns
- 45 days, by mail
- Warranty
- See warranty terms
- Payment
- Bank transfer, Zelle, Chime
Product details
Model Number: CAD-EL | Part Number: 485 80113 00
- Maximum Capacity 9,000 lbs / 4,082 kg each
- Overall Width 11.5 in / 29.2 cm
- Overall Length 37 in / 94 cm
- Minimum Starting Height 16 in / 40.6 cm
- Minimum Lift Pad Spread-Center to Center 20 in / 50.8 cm
- Maximum Lift Pad Spread-Center to Center 32 in / 81.3 cm
- Minimum Lift Pad Clearance from Cross Member 5 in / 12.7 cm
- Maximum Lift Pad Clearance from Cross Member 7.5 in / 19.1 cm
- Lift Pad Diameter 3 in / 7.6 cm
- Base Pad Spread-Center to Center 26.5 in / 67.3 cm
- Shipping Weight 80 lbs / 36.3 kg
Call 216-250-6666 or email sales@varietyengines.com with your ceiling height, floor and power supply and we will check the install and freight with you before you order. More Mobile Column Lifts.
