Forward Lift BP-9 9,000 lb ALI Certified Two-Post Lift
Forward Lift BP-9 9,000 lb ALI Certified Two-Post Lift

Forward Lift BP-9 9,000 lb ALI Certified Two-Post Lift

$6,415.00

The Forward Lift BP-9 Two-Post Lift is a 9,000-lb. ALI Certified two-post car lift. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.

In Stock
Category:
Brand:

Description

Additional Features:

  • Dual hydraulic cylinders
  • Low-Profile Threaded Adapters
  • Carriage latch system – engages every 3″
  • Secondary lock system includes a spring actuated slack chain locking device
  • Adapter extensions included
  • Powder coat, oven baked finish

Specifications

Specifications BP9113000
Total Capacity 9,000 lbs. (4082kg)
Overall Height 111-1/4″ (2826mm)
Overall Width 138-1/2″ (3518mm)
Rise With Extensions 80-1/2″ (2045mm)
Rise Without Extensions 72″ (1829mm)
Drive Through Clearance 97-1/4″ (2470mm)
Width Inside Columns 111″ (2819mm)
Arm Reach (Min./Max.) 30″/46-1/4″ (762mm/1174mm)
Minimum Adapter Height 4-1/2″” (114mm)
Drive-Over Height 1-1/2″ (38mm)
Voltage/Amps 208/230, 20 Amps
Motor 2 HP/1Ø* (38mm)
Minimum Ceiling Height 113″ (2870mm)
*Optional 3-Phase available.

Call 216-250-6666 or email sales@varietyengines.com with your ceiling height, floor and power supply and we will check the install and freight with you before you order. More Two Post Lifts.
