Bendpak 12APX-192 12,000-lb. Capacity ALI Certified / Clearfloor / Screw Pads / High-Rise / 192″ O.A. Height
$13,295.00
The BendPak 12APX-192 Capacity / Clearfloor / Screw Pads / High-Rise / 192″ O.A. Height is a 12,000-lb. ALI Certified clearfloor four-post lift. Confirm your ceiling height, floor and power supply before ordering — we ship by freight and can check the install with you.
In Stock
Description
Shop the Bendpak 12APX-192 12,000-lb. Capacity ALI Certified / Clearfloor / Screw Pads / High-Rise / 192″ O.A. Height at Variety Engines — every unit is carefully inspected, warrantied, and ready to ship fast across the US.
Specifications
- 12K LBS. Lifting Capacity
- Bi-Metric™ Lifting
- Low-Pro™ Triple-Telescoping Arms
- Performance Guaranteed*
- Adaptable Design: Symmetric or Asymmetric
- Automatic Swing Arm Restraint System (ASARS)
- Durable Powder Coat Finish
- Expandable Top Beam
- Double-Telescoping Screw Pads
- Padded Overhead Safety Shutoff Bar
- Exclusive Bi-Metric™ Arm Design
- Single-Point Safety Release
- Drop-End Arms
- Dual Hydraulic Direct-Drive Cylinders
- Electric/Hydraulic HVLP Power System
- Self-Lubricating Dura-Glide UHMW Polyethylene Bearing System
- Safety Locks in Each Column
- Heavy-Duty Aircraft-Quality Equalizer Cables
- Oversized Cable Sheave Diameter
- Four-Triple Telescoping Arms
Accessories Included:
- 2.5″ Medium Adapters (Set of 4)
- 5″ Tall Adapters (Set of 4)
- Adapter Holders (Set of 2)
- Drop-In Cradle Pads (Set of 4)
Optional Accessories:
- Quick-Fit Pinch-Weld Pucks (Set of 4)
- Quick-Fit Pinch-Weld Pads (Set of 4)
- Wide Frame Cradle Adapters (Set of 2)
- 2″ Low Adapter (Set of 4)
- Steel Lift Pads (Set of 4)
- Replacement Urethane Pads (Set of 4)
- Screw Pads (Set of 4)
Model 12APX-192
Max. Lifting capacity: 12,000 lbs. / 5,443 kg
A – Max. Rise: 75.75 in. / 1,922 mm
B – Lifting Height w/Pad down: 78.50 in. / 1,992.3 mm
C – Max. Lifting Height w/ Pad up: 82.5 in. / 2,095 mm
D – Min. Height w/ Pad: 4 in. / 101.2 mm
E – Overall Height: 193 in. / 4,904 mm
F – Overall Width: 156 in. / 3,959 mm
G – Width, Outside Posts: 143 in. / 3,238 mm
H – Width, Inside Posts: 120 in. / 3,047 mm
I – Width, Drive-Thru: 103 in. / 2,616 mm
J – Floor to Top Switch: 186.50 in. / 4,738.5 mm
K – Front Arm Reach (min): 55.25 in. / 1,404.2 mm (max)
L – Rear Arm Reach: 60 in. / 1,524.4 mm (max)
Max. load per Lift Arm: 3,000 lbs. / 1,361 kg
Pad Adapters Total Height: 7.50 in. / 188 mm
Time to Full Rise: ≈ 45 seconds
Motor: 220 VAC, 60 Hz, 1 Phase
Sound: <70 dB
About the Bendpak 12APX-192 12,000-lb. Capacity ALI Certified / Clearfloor / Screw Pads / High-Rise / 192″ O.A. Height
This unit is quality-tested and ready to install. Browse more Four Post Lifts, or contact our team with your VIN for fitment help — with fast, tracked shipping on every order.
